Xiamen XingRuiJia is a supplier of
GE IC755CSW07CDA QuickPanel+Operator terminal
and will be your good helper. Please feel free to inquire for more details.
Features:
The IC755CSW07CDA is a QuickPanel+ Operator terminal. It is part of the Visualization product catalog that is manufactured by Emerson Automation, formerly by GE Intelligent Platforms (GE IP). It functions as a Human Machine Interface (HMI), featuring an embedded display measuring 7-inch widescreen TFT LCD screen with resolution of 800 x 480 pixels. It comes with a projected capacitive, multi-touch interface and an Intel Freescale i.MX535 1 GHz ARM Cortex A8 processor. The integrated memory available to this HMI includes 512 MB DDR2 SDRAM; 256 MB SLC NAND Flash and 512 KB SRAM. For communication, this device has One (1) Ethernet, and One (1) RS232 communication ports. This terminal operates at an input supply voltage of 24 VDC.
The IC755CSW07CDA is a QuickPanel+ operator terminal from Emerson automation. This device is popularly termed as Human Machine Interface (HMI) or Operator Interface Terminal (OIT) by most personnel in the industry as this electronic device is primarily used to provide real-time monitoring and control capability of the connected machine or process through the embedded 7-inch widescreen display with resolution of 800 x 480 pixels and the multi-touch operator input interface. In addition, this terminal is also capable of functioning as a controller, machine gateway and data historian.
The IC755CSW07CDA is an HMI device that supports panel mounting or VESA 75 installation. It requires an input supply voltage of +24VDC ±20% terminated to the provided 3-pin Phoenix type connector. This device also has a maximum power consumption of 15 Watts. It uses natural convection for device cooling and must be installed at an application area with temperature range of 0-55 Degrees Celsius and 85% relative humidity.
